The FitSteel wire mesh sheets are special mesh reinforcements that can be arranged with the main reinforcement being in one or two directions.
The FitSteel special mesh reinforcements can meet all construction work requirements, including the reinforcement of slabs, walls, foundation slabs and beams, while offering time and labor cost saving and ensuring strict compliance with design specifications.
Can be used as single flat sheets to reinforce surface structures.
Technical Characteristics
|
|
Advantages |
|
Production Range
|
Length( m) | 0,80 – 15,00 |
Width (m) | 1,20 – 3,45 |
Diameter of line rebars (mm) | 6 – 25 |
Diameter of cross rebars (mm) | 6 – 16 |
Line rebar spacing (mm) | 75 and over |
Cross rebar spacing (mm) | 50 and over |
Distance between opposite line rebars (mm) | 3.200 |
Edge length | upon request |
Note: Due to transportation restrictions, the wire mesh length or width must be equal or less than 2.60m
The FitSteel special mesh reinforcements are available in two types:
FitSteel 1
The line rebars in this wire mesh are made of B500C steel while the cross reinforcements are Ø6 diameter round wire rods.
FitSteel 2
The line and cross rebars of this wire mesh are made of B500C steel
